Synopsis
Every high-performance conference setup requires a central intelligence to manage the complex flow of data and acoustics. The BR-DCU-CU2000-D Digital Conference Controller serves as this sophisticated “brain,” specifically engineered to drive the next generation of digital conference systems. Utilizing a unique digital ring network technology, it allows for the transmission of 64 channels of high-fidelity audio over a single CAT5e cable. With advanced features like System Date and Time Management, Count-down Speech Support, and an optional Dante output module, it offers unparalleled control and integration capabilities. Whether managing multiple conference rooms or providing the processing power for 5,200 units through extension modules, the BR-DCU-CU2000-D ensures total stability and crystalline sound for every professional conferencing solution.
Table of Content
-
The Central Intelligence of Audio
-
The BR-DCU-CU2000-D – Full Digital Processing Power
-
64-Channel Transmission over a Single CAT5e Cable
-
Procedural Precision: Time Management and Count-down Speech
-
Networking Beyond Boundaries: Optional Dante Integration
-
Advanced DSP for Acoustic Perfection
-
Feedback Suppression and Voice Role Separation
-
Scalability for Large-Scale Assemblies
-
Bronx – Specialists in Unified Control Systems
-
Governing the Future of Institutional Dialogue
In the realm of formal discussion—be it a parliament, a corporate board, or a judicial hearing—order is just as important as clarity. A “brainless” system often leads to audio feedback, chaotic speaking queues, and technical failures. The BR-DCU-CU2000-D Digital Conference Controller provides the administrative and technical muscle needed to govern even the most complex digital conference systems, ensuring that every meeting proceeds with professional decorum
The BR-DCU-CU2000-D - Full Digital Processing Power
The BR-DCU-CU2000-D is a full-digital networked DSP processor. Unlike legacy analog controllers, it maintains absolute signal purity from input to output, delivering a frequency response of
64-Channel Transmission over a Single CAT5e Cable
Connectivity is revolutionized through the use of CAT5e cabling, which transmits up to 64 channels of audio alongside various control information. This “Hand-in-Hand-Loop-Network” technology not only simplifies the installation of advanced AV integration projects but also provides a self-healing loop. If a single unit malfunctions or a cable is disconnected, the rest of the conferencing equipment remains perfectly operational.
Product Preview: Bronx BR-DCU-CU2000-D
The BR-DCU-CU2000-D is the central hub for wired digital conferencing, offering 64-channel transmission, Dante compatibility, and advanced speech management.
Centralise your meeting control with the Bronx BR-DCU-CU2000-D here
Procedural Precision: Time Management and Count-down Speech
Strict adherence to time is a hallmark of professional assemblies. The BR-DCU-CU2000-D features integrated System Date and Time Management. More importantly, it supports Count-down Speech functionality, allowing the moderator to set strict time limits for speakers. This ensures that every participant has a fair chance to contribute, making it an essential tool for professional conferencing solutions in legislative and regulatory environments.
Networking Beyond Boundaries: Optional Dante Integration
To bridge the gap between local audio and the wider facility network, the controller offers an Optional Dante output module. This allows the BR-DCU-CU2000-D to interface seamlessly with other Dante-enabled equipment, such as networked amplifiers, recording suites, or external DSPs. This network-first approach ensures that your digital conference systems are fully integrated into the broader audio and video conferencing infrastructure of the building.
Advanced DSP for Acoustic Perfection
The controller is equipped with sophisticated Digital Signal Processing (DSP) to handle the room’s acoustics automatically.
Feedback Suppression and Voice Role Separation
With built-in AFC (Adaptive Feedback Suppression) and AGC (Automatic Gain Control), the unit prevents the “whistle” of feedback and levels out the volume of different speakers. A unique feature is its support for Voice Role Separation. By providing independent ID outputs for each microphone, the system can work with third-party voice recognition software to create automated, speaker-attributed transcripts—a powerful asset for professional conferencing solutions.
Scalability for Large-Scale Assemblies
The BR-DCU-CU2000-D is built to grow. A single controller can manage and merge up to four conference rooms independently. For massive installations, it can be connected to the BR-DCU-EXM extension main unit, expanding the system’s capacity to a staggering 5,200 discussion units. This makes it the definitive choice for conferencing equipment in convention centers and international summit halls.
Bronx - Specialists in Unified Control Systems
At Bronx, we specialize in the “brain” of the boardroom . We provide the BR-DCU-CU2000-D Digital Conference Controller as a core component of our advanced AV integration services, ensuring that your organization has total command over its sonic and procedural environment.
Governing the Future of Institutional Dialogue
By choosing the BR-DCU-CU2000-D, you are investing in a system that values clarity, redundancy, and efficiency. We guarantee that your digital conference systems will deliver a professional, structured, and uninterrupted experience for every participant, every time.
FAQs
How does the "Count-down Speech" feature benefit my meetings?
The Count-down Speech feature allows the chairman to set a specific time limit for each speaker. The time remaining can be displayed on the delegate units, ensuring that participants stay concise and that the meeting follows a strict schedule—a vital component of professional conferencing solutions.
Is the Dante output module included as standard?
The Dante output module is optional. It allows the BR-DCU-CU2000-D to transmit uncompressed audio over an IP network to other Dante-compatible conferencing equipment, providing massive flexibility for advanced AV integration.
What happens if a delegate unit is accidentally disconnected?
Thanks to the “Hand-in-Hand-Loop-Network” technology, the controller automatically reroutes the signal from the other side of the loop. This ensures that the rest of your digital conference systems stay active and the meeting continues without interruption.
Can this controller drive speakers directly?
Yes. The BR-DCU-CU2000-D can drive $2 \times 120\text{W}$ POE speakers directly from the unit. With an extension main unit, it can support up to 16 POE speakers, making it a comprehensive hub for audio and video conferencing.
How does the "Voice Role Separation" work for transcription?
Because the controller assigns an independent ID to every microphone, it can output individual audio streams for each speaker. When connected to a voice recognition system, this allows for the creation of accurate, speaker-named transcripts for your professional conferencing solutions.
